STA-U20X Laser Range Finder Module Features

Safe and harmless to eyes
●Using 905nm semiconductor laser, safe for eyes.
●High reliability and long service life.

Easy operation and secondary development
●Adopt TTL interface, equipped with instruction set and communication protocol, which is convenient for users to develop twice.

Exchange Optimization
●With its very small size and ultra-light design and optimized power consumption, the STA-U20X is ideal for a variety of handheld devices, portable thermal imaging systems and lightweight sensor kits.

Large measuring range and high precision
● Maximum measuring range ≥ 2400m (white wall)
● Measuring tree range ≥ 2000m
● Distance measurement accuracy ± 1m. High precision, more accurate distance measurement results.
● Weight ≤ 42g. Light weight and small size.

Applications of STA-U20X Rangefinder Module

Product features

●Integrated design of the whole machine structure, small size, light weight, anti-shock vibration, high reliability, strong environmental adaptability;

●Using a 905nm semiconductor laser for eye safety;  Comes with a red dot laser indicator for easy calibration of modules and equipment.

●Using advanced transmitting antenna shaping technology, good beam quality, high coupling efficiency, strong optical axis stability, and good adaptability to severe weather

Product performance index
