High-performance OEM laser rangefinder sensor solutions empower your innovation.
With expertise and cutting-edge proprietary technology, Jioptics can provide 100m-4000m reliable 905nm laser rangefinder solutions to meet your different needs.
The 905nm rangefinder module is widely used in night vision, thermal imaging, UAV pod and other equipment integration.
We provide customized ODM services for specific needs to help you solve any technical problems and help you innovate.
WORKING PRINCIPLE OF LASER RANGEFINDER MODULE
A long range laser rangefinder emits an extremely thin laser beam towards the target during operation. When the photoelectric element receives the laser beam reflected by the target, the timer measures the time from transmission to reception of the laser beam and calculates the distance from the observer to the target.
905nm Laser Range Finder Module
1535nm Laser Range Finder Module
1570nm Laser Range Finder Module
1064nm Laser Target Designatol
Product display
-
2300m Laser Rangefinder Module
STA-M18X uses a 905nm semiconductor eye safety laser with low power consumption, small size and high precision, which is suitable for handheld mobile devices, UAV pods and other equipment integration.
Measuring range:5-2300m
Measuring the Tree≥1800m
Measuring the Deer≥1200m
Measuring accuracy ±1m
Measuring accuracy ≥98%
Weight ≤32 g¥ 0.00Buy now
-
4500m Laser Rangefinder Module
STA-M40X uses a 905nm semiconductor eye safety laser with low power consumption, small size and high precision, which is suitable for handheld mobile devices, UAV pods and other equipment integration.
Measuring range:5-4500m
Measuring the Tree≥3300m
Measuring the Deer≥2500m
Measuring accuracy ±1m
Measuring accuracy ≥98%
Weight ≤38 g¥ 0.00Buy now
-
3500m Laser Rangefinder Module
STA-M30X uses a 905nm semiconductor eye safety laser with low power consumption, small size and high precision, which is suitable for handheld mobile devices, UAV pods and other equipment integration.
Measuring range:5-3500m
Measuring the Tree≥2400m
Measuring the Deer≥1800m
Measuring accuracy ±1m
Measuring accuracy ≥98%
Weight ≤38 g¥ 0.00Buy now
-
2300m Laser Rangefinder Module
STA-M18X uses a 905nm semiconductor eye safety laser with low power consumption, small size and high precision, which is suitable for handheld mobile devices, UAV pods and other equipment integration.
Measuring range:5-2300m
Measuring the Tree≥1800m
Measuring the Deer≥1200m
Measuring accuracy ±1m
Measuring accuracy ≥98%
Weight ≤32 g¥ 0.00Buy now
-
1200m Laser Rangefinder Module
STA012X uses a 905nm semiconductor eye safety laser with low power consumption, small size and high precision, which is suitable for handheld mobile devices, UAV pods and other equipment integration.
Measuring range ≥5-1200m(Tree)
Maximum measuring distance ≥1500m(Typical target)
Measuring accuracy ±1m
Measuring accuracy ≥98%
Weight ≤21 g¥ 0.00Buy now
-
30hz Laser Rangefinder Module
The rangefinder module can provide measurement data for the main control system quickly and accurately. The module adopts 905nm semiconductor laser, ranging resolution is 0.1m, ranging accuracy is 1m; Ranging frequency up to 30Hz, is a high integration, low power consumption, light weight of the miniaturized rangefinder module. Ideal for integrating handheld mobile devices and drone pod systems.¥ 1600.00Buy now
Jioptic provides you with high performance laser rangefinder sensors, thermal imaging, phased array radar (low altitude UAV and ground moving target tracking surveillance), laser rangefinder binoculars etc products.
We look forward to your inquiry
